Cable Locator Wire Finder Tester Tracer Set Plus Carry Case
Hover over image to zoom
)
Product Description
This professional general purpose cable lacator is ideal for tracing cables in walls and underground, locating fuses/breakers on final circuits and locating interruptions and short-circuits in cables and electrical floor heating systems. It can also be used for tracing metallic water and heating pipes. The unit is supplied as a complete kit comprising of a transmitter and receiver in a purpose made carry case. The receiver also incorporates a torch function for working in dim light location.
Features:
- For all applications ( live or dead cable ) without additional instruments
- Set includes a transmitter and a receiver
- Proven digitally coded sender signal guarantees clear signal identification
- Transmitter with LCD-display for transmitting level, transmitting code and external voltage
- Receiver with back light LCD display for level of receiving signal, code of receiving signal and live voltage indication
- Automatic or manual adjustment of receiving signal sensitivity
- Acoustical receiving signal switchable
- Auto power off
- Additional torch lamp function for working in dark environment
Specifications:
- Voltage measurement range: Transmitter: 12V, 50V, 120V, 230V, 400V
- Frequency range: Transmitter: 0...60Hz
- Output signal: Transmitter: 125kHz
- Voltage: Transmitter: up to 400V AC/DC
- Tracing depth cable location: Receiver: 0...2.5m wall/underground cables
- Main voltage detection: Receiver: 0...0.4m
Environment Specifications:
- Operating temperature: Transmitter: 0 to 40 °C,Receiver: 0 to 40 °C
- Storage temperature: Transmitter: -20 °C to 60 °C, Receiver: -20 °C to 60 °C
- Humidity (without condensation: Transmitter: Max. 80% relative, Receiver: Max. 80% relative
- Operating Altitude: Transmitter up to 2000m, receiver up to 2000m
Safety Specifications:
- Electrical safety: EN61010-1
- Overvoltage category: CAT III 300V
Size ( Hx Wx D): 190mm x 60mm x 37mm
Weight: 229g
What's In The Box
 |
|
 |
 |
 |
 |
Warranty Information
Other Details
Find Similar Products by Category
Product Reviews
-
Works Great
Posted by Dave on 11th Mar 2016
It helped me locate lost wires behind walls easily. Same as the Fluke model at over $700 and it works the same.
-
great tool
Posted by peter hampton on 29th Aug 2014
was thinking for the price it would not work well.As i have used many other types,but at first use i was able to locate a short in a power line located in a roof space and whats better i did not even have to get in the roof space to find it, great tool and worth the money.
30 years electronics Peter Ballina............29/8/2014
